Chevron Cylinder Oils W are recommended for lubrication of compressor cylinders and sliding worm gear surfaces in worm drive gear cases.
Where to buy ›
Delivering value for you
and high film strength for any moisture condition.
Three viscosity grades available to cover the range of steam pressures and temperatures found in industry.
Can be used as worm gear lubricants. Meets AGMA compounded lubricant specifications.
Applications
Compressor manufacturers often recommend cylinder oils for compressor cylinder lubrication. The oiliness of Chevron Cylinder Oils W promotes a metal wetting characteristic that resists the washing action of water and maintains a tenacious oil film on the surface of the compressor cylinder. The low viscosity of Chevron Cylinder Oil W 220 makes it suitable for this application in colder climates.
Chevron Cylinder Oil W 460 is recommended for moderate service applications where steam pressures will not exceed 150 psi and temperatures vary between 171°C to 204°C (340°F to 400°F).
Chevron Cylinder Oil W 680 is a higher viscosity lubricant recommended for steam pressures up to 300psi and temperatures from 218°C to 302°C (425°F to575°F).
Chevron Cylinder Oils W are ideal choices for worm gears.
Chevron Cylinder Oils W are recommended for use in underground brine pumps at geothermal power generation facilities.
Chevron Cylinder Oils W 220, 460, and 680 meet the requirements of ANSI/AGMA 9005-E02 for AGMA Lubricant Numbers 5, 7 Compounded, and 8 Compounded, respectively
